General Atomics supplies complete, low-loss, low-power corrugated waveguide transmission systems that are engineered to perform exceptionally over broad frequency bands—particularly in larger diameters. This inherent efficiency makes their systems ideal for advanced diagnostic and measurement applications, including electron cyclotron emission diagnostics, reflectometers, interferometers, and radiometers.

General Atomics supplies complete transmission systems by supplementing

Corrugated Waveguide with components such as:

• Arc Detectors (see Miter Bends)
• Beam Combiners / Splitters
• Bragg Reflection Notch Filters
• Calorimetric Miter Bends
• Circular Polarizers
• Continuous Curvature Bends*
• Corrugated Horn Antennas
• DC Breaks
• Diameter Tapers*
• Directional Couplers (in smooth waveguide)
• Dummy Loads
• Low Pass Filters
• Miter Bends*
• Mode Converters*
• Polarization Rotators
• Polarizer Miter Bends
• Power Monitor Miter Bends
• Remotely Controlled Polarization Rotators and Grid Polarizers
• Steering Antennas
• Transitions from Fundamental Rectangular Waveguide (for testing)
• Transitions from Fundamental Rectangular Waveguide
• Vacuum Windows
• Waveguide Bellows
• Waveguide Flange Adapters
• Waveguide Switches
• Waveguide Pumpout Tees

*Components marked with an asterisk are available for smooth waveguide as well as corrugated waveguide transmission systems. Other components may be modified for smooth waveguide as well.
